| Size & Capacity (lbs) | 5 | 10 | 15 | 20 |
| U/L Rating | 5B:C | 10B:C | 10B:C | 10B:C |
| Valve Material | Aluminum 6061 | |||
| Cylinder Diameter (mm) | 133 | 175 | 175 | 203 |
| Cylinder Depth ( mm) | 370 | 430 | 600 | 600 |
| Cylinder Volume (ml) | 3.4 | 6.8 | 10.2 | 13.5 |
| Cylinder Weight (kg) | 3.1 | 6.0 | 7.8 | 10.5 |
| Discharging Time ( second) | 10 | 10 | 15 | 20 |
| Discharging Range (m) | 1.83 - 3.65 | |||
| Working Pressure (Bar) | 310 | |||
| Working Temperature (ºC) | -30° - 60° | |||
| Application | Nozzle | Hose & Nozzle | ||
| Standard Bracket | Wall | |||
Welcome to become one of our distributors worldwide. If you have interest please contact us.
