| Model No. | PG1A | PG2A | PG4A | PG6A | PG9A |
| Agent | 1kg ABC chemical powder | 2kg ABC chemical powder | 4kg ABC chemical powder | 6kg ABC chemical powder | 9kg ABC chemical powder |
| Propellant | Nitrogen Gas | Nitrogen Gas | Nitrogen Gas | Nitrogen Gas | Nitrogen Gas |
| Material | ST12/ST14 | ST12/ST14 | ST12/ST14 | ST12/ST14 | ST12/ST14 |
| Valve | M24*1.5 Pressure Relieve Valve with CE Approval | M30*1.5 Pressure Relieve Valve with CE Approval | M30*1.5 Pressure Relieve Valve with CE Approval | M30*1.5 Pressure Relieve Valve with CE Approval | M30*1.5 Pressure Relieve Valve with CE Approval |
| Working pressure | 14Bar at 20℃ | 14Bar at 20℃ | 14Bar at 20℃ | 14Bar at 20℃ | 14Bar at 20℃ |
| Test pressure | 30Bar | 30Bar | 30Bar | 30Bar | 30Bar |
| Volume | 1.25L | 2.5L | 5.1L | 7.6L | 11.2L |
| Fire rating | 5A/34B/C | 13A/55B/C | 13A/89B/C | 27A/183B/C | 43A/233B/C |
| Discharge time | >9'S | >12'S | >14'S | >16'S | >17'S |
| Discharge range | 3-5m | 4-6m | 5-7m | 6-8m | 6-8m |
| Operating temperature | -30℃ ~ +60℃ | -30℃ ~ +60℃ | -30℃ ~ +60℃ | -30℃ ~ +60℃ | -30℃ ~ +60℃ |
| Finishing | Powder coating UV Resistance | Powder coating UV Resistance | Powder coating UV Resistance | Powder coating UV Resistance | Powder coating UV Resistance |
| Extinguisher weight | 2.2kg | 3kg | 6.8kg | 9kg | 14.3kg |
| Cylinder size (D*H) | 85mm*267mm | 110mm*316mm | 140mm*391mm | 161mm*434mm | 183mm*496mm |
| Packing size (L*W*H) | 107mm*107mm*358mm | 140mm*140mm*420mm | 160mm*160mm*485mm | 180mm*180mm*555mm | 195mm*195mm*6 |
Welcome to become one of our distributors worldwide. If you have interest please contact us.
